ZK140T de Luxe

ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 653623) R-Player

ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 653624) R-Player

ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 653625) R-Player
ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 350878) R-Player ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 350874) R-Player
ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 350875) R-Player ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 350877) R-Player
ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 2427805) R-Player ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 2427806) R-Player
ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 648533) R-Player ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 648534) R-Player
ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 648535) R-Player ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 648536) R-Player
Use red slider bar for more.
ZK140T de Luxe; Unitra ZRK, Zaklady (ID = 350878) R-Player
Unitra ZRK, Zaklady: ZK140T de Luxe [R-Player] ID = 350878 933x630
Select picture or schematic to display from thumbnails on the right and click for download.
For model ZK140T de Luxe, Unitra ZRK, Zaklady Radiowe im. M. Kasprzaka

Country:  Poland
Manufacturer / Brand:  Unitra ZRK, Zaklady Radiowe im. M. Kasprzaka
Brand

Unitra
Year: 1970 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 9: BC109 BC527 BC527 BC527 BC527 BC527 BC528 AD161 AD162
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: ZK140T de Luxe - Unitra ZRK, Zaklady Radiowe im
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 395 x 175 x 290 mm / 15.6 x 6.9 x 11.4 inch
Notes Vierspur; Bandgeschwindigkeit: 9,53 cm/s, Übertragungsbereich: 40···12500 Hz, Eingänge für Mikrofon, Plattenspieler, Radio. Ausgänge: Zweitlautsprecher, Überspielausgang. Bedienung mittels 1-Knopf-Drehschalter, Lizenz: Grundig.
Parallelgerät zu: TK140 de Luxe.
Net weight (2.2 lb = 1 kg) 7.8 kg / 17 lb 2.9 oz (17.181 lb)
Mentioned in Die Geschichte der Fonoindustrie der DDR 1945 bis 1990
Literature/Schematics (1) Importgeräte- CD, Funkverlag B. Hein

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Unitra ZRK, Zaklady Radiowe im. M. Kasprzaka
Here you find 212 models, 181 with images and 86 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
