For model 12-S-245 Ch=1204, Zenith Radio Corp.; Chicago, IL:
12-S-245 (Ch=1204) 1937 open-view ebay seller puetts

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12: 6K7G 6L7G 6J5G 6K7G 6T5 6H6G 6J5G 6J5G 6J5G 6V6G 6V6G 5Y4G
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 15 W (unknown quality)
from Radiomuseum.org Model: 12-S-245 Ch=1204 - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console: Chairside Radio.
Dimensions (WHD) 31.9 x 20 x 20.6 inch / 810 x 508 x 523 mm
Notes The schematic diagram got corrections (red). These lines are already missing in the Zenith drawing as well as in Riders and in Beitman.
Price in first year of sale 150.00 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 8 = 1937 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) Zenith Radio The Glory Years 1936-1945
