For model 5S327 Ch= 5529, Zenith Radio Corp.; Chicago, IL:
With courtesy by Ebayseller larry21751

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A8G 6K7G 6Q7G 6K6G 6X5G
schematic requested
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
Power out 3 W (unknown quality)
from Radiomuseum.org Model: 5S327 Ch= 5529 - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 11.5 x 15.9 x 7.6 inch / 292 x 404 x 193 mm
Notes

Small tombstone. With automatic Tip-Touch Tuning.

Stein (Cathedral & Tombstone) calls this model erroneously "5R327".

Price in first year of sale 30.00 $
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 9 = 1938 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) Zenith Radio The Glory Years 1936-1945
Literature/Schematics (2) Cathedral & Tombstone Radios (page 284.)
Literature/Schematics (3) -- Original prospect or advert (The Zenith Folder for 1939.)
