6S302 6-S-302 Ch=5651
Zenith Radio Corp.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Zenith Radio Corp.; Chicago, IL
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 67875
-
- alternative name: Chicago Radio Lab
Click on the schematic thumbnail to request the schematic as a free document.
- from Radiomuseum.org
- Model: 6S302 6-S-302 Ch=5651 - Zenith Radio Corp.; Chicago,
- Notes
- Model not existing ! Number created by misinterpretation of Riders Vol.9-15, where the chassis 5651 is stated for 6S301 to 6S306. The same sheet clearly shows in the speaker listing that 3S302 is not existent.
- External source of data
- Ernst Erb
