8A128 Ch=5802A; Zenith Radio Corp.; (ID = 125086) Radio
Zenith Radio Corp.;: 8A128 Ch=5802A [Radio] ID = 125086 373x452
Select picture or schematic to display from thumbnails on the right and click for download.
For model 8A128 Ch=5802A, Zenith Radio Corp.; Chicago, IL:
Radio shown before restauration

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6K7G 6C5G 6A8G 6K7G 6H6G 6F5G 6F6G 5Y3 or 5W4
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
Power out 5 W (unknown quality)
from Radiomuseum.org Model: 8A128 Ch=5802A - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 420 x 570 x 310 mm / 16.5 x 22.4 x 12.2 inch
Notes Export model for 25-133cycles mains; Shadow meter.
Source of data -- Collector info (Sammler)
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before

Model page created by Mikael Carlsson. See "Data change" for further contributors.



All listed radios etc. from Zenith Radio Corp.; Chicago, IL
Here you find 4275 models, 3894 with images and 3389 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
