For model 9S344 9-S 344 Ch=5907, Zenith Radio Corp.; Chicago, IL:
9-S-344 (Ch=5907) 1938 Ebay seller zenith_sparton

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: 6K7G 6L7G 6J5G 6K7G 6U5 6J5G 6F5G 6F6G 5Y4G
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10 inch = 25.4 cm
Power out
from Radiomuseum.org Model: 9S344 9-S 344 Ch=5907 - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console: Chairside Radio.
Dimensions (WHD) 29.1 x 21.5 x 16.5 inch / 739 x 546 x 419 mm
Notes Pushbuttons
Price in first year of sale 100.00 $
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 9 = 1938 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) Zenith Radio The Glory Years 1936-1945
