For model A519F Ch= 5A07, Zenith Radio Corp.; Chicago, IL:
eigenes Geraet

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AV6 50C5 35W4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: A519F Ch= 5A07 - Zenith Radio Corp.; Chicago,
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 330 x 140 x 170 mm / 13 x 5.5 x 6.7 inch
Notes

The Zenith Modell A519F is an AC Operated 5 Tube AM Superheterodyne Receiver with Electric Clock. Built-in loop antenna.

Caution: Hot chassis! Use isolation transformer during repair.


Netzzuleitung liegt einseitig am Chassis, einpoliger Netzschalter und keine Sicherung!

Eingebaute Rahmenantenne, an der Rückwand befestigt.

Net weight (2.2 lb = 1 kg) 2.2 kg / 4 lb 13.5 oz (4.846 lb)
