Colonial Deluxe Zenith early, battery

Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764690) Radio Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764686) Radio
Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764691) Radio Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764683) Radio
Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764685) Radio Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764687) Radio
Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764689) Radio Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764688) Radio
Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764692) Radio Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764693) Radio
Use red slider bar for more.
Colonial Deluxe Zenith early, battery; Zenith Radio Corp.; (ID = 764690) Radio
Zenith Radio Corp.;: Colonial Deluxe Zenith early, battery [Radio] ID = 764690 404x363
Select picture or schematic to display from thumbnails on the right and click for download.
For model Colonial Deluxe Zenith early, battery, Zenith Radio Corp.; Chicago, IL:
Zenith model Colonial de-Luxe with courtesy by Ebayseller hanoverantiques.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1926 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10:
Main principle TRF without regeneration
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker
Power out
from Radiomuseum.org Model: Colonial Deluxe Zenith early, battery - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes Two speakers! Two dials (primary tuning control knobs); tuned 100-550meters;
Price in first year of sale 500.00 $
Mentioned in Zenith Radio The Early Years 1919-1935

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
