For model D3007E, M, R, W, Y, D3008R, Ch= 16D21Q, Zenith Radio Corp.; Chicago, IL:
Copy from Zenith folder.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1959/1960 Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 21CXP4
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: D3007E, M, R, W, Y, D3008R, Ch= 16D21Q - Zenith Radio Corp.; Chicago,
Material Wooden case
Shape Console with any shape - in general
Notes ~21" b/w TV with US standard VHF "Target Tuner". Zenith "Space Command" remote control. An additional suffix "U" stands for factory equipped with continuous UHF tuner. Exactly tube quantity unknown.
Source of data -- Original-techn. papers.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 12-59, Set 467, Folder 2)
