Filter Unit ZE8

Filter Unit ZE8; Zenith Radio Corp.; (ID = 342067) Power-S
Filter Unit ZE8; Zenith Radio Corp.; (ID = 898370) Power-S
Use red slider bar for more.
Filter Unit ZE8; Zenith Radio Corp.; (ID = 898370) Power-S
Zenith Radio Corp.;: Filter Unit ZE8 [Power-S] ID = 898370 600x577
Select picture or schematic to display from thumbnails on the right and click for download.
For model Filter Unit ZE8, Zenith Radio Corp.; Chicago, IL:
Zenith_model_English DeLuxe using ZE8 Filter and ZE 7 Power supply.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1928 ? Category: Power supply/conditioner or battery or charger
Details
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Filter Unit ZE8 - Zenith Radio Corp.; Chicago,
Shape Chassis only or for «building in»
Notes Filter Unit in conjunction with Power Supply ZE7
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 7 = 1936 and before
