H401 Ch= 4H40

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 151188) Radio

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 151189) Radio

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 240721) Radio

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 507648) Radio

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 507650) Radio

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 507653) Radio

H401 Ch= 4H40; Zenith Radio Corp.; (ID = 507655) Radio
H401 Ch= 4H40; Zenith Radio Corp.; (ID = 188814) Radio H401 Ch= 4H40; Zenith Radio Corp.; (ID = 323025) Radio
H401 Ch= 4H40; Zenith Radio Corp.; (ID = 323026) Radio H401 Ch= 4H40; Zenith Radio Corp.; (ID = 323027) Radio
H401 Ch= 4H40; Zenith Radio Corp.; (ID = 711363) Radio H401 Ch= 4H40; Zenith Radio Corp.; (ID = 1046304) Radio
Use red slider bar for more.
H401 Ch= 4H40; Zenith Radio Corp.; (ID = 188814) Radio
Zenith Radio Corp.;: H401 Ch= 4H40 [Radio] ID = 188814 320x240
Select picture or schematic to display from thumbnails on the right and click for download.
For model H401 Ch= 4H40, Zenith Radio Corp.; Chicago, IL:
H-401 Ebay seller tmoen5gri

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1952 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1U4 1S5 3V4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Line / Batteries (any type) / (1.5; 67.5); AC/DC 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: H401 Ch= 4H40 - Zenith Radio Corp.; Chicago,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes Selenium Rectifier
Source of data Rider's Perpetual, Volume 22 = covering 1951
Circuit diagram reference Beitman Radio Diagrams Vol. 12, 1952
Mentioned in Collector's Guide to Antique Radios (6th edition)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 1-52, Set 156, Folder 15)

Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
