For model S13675, Zenith Radio Corp.; Chicago, IL:
With courtesy by Ebayseller unitroncollector.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1950 ?? Category: Sound/Video Recorder and/or Player
Valves / Tubes 1: 7F7
Main principle Audio-Amplification
Wave bands - without
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: S13675 - Zenith Radio Corp.; Chicago,
Shape Chassis only or for «building in»
Notes maroon Record Changer
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
