• Year
  • 1958 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 323360
    • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: S-14083 - Zenith Radio Corp.; Chicago,
  • Shape
  • Chassis only or for «building in»
  • Notes
  • The Zenith Cobra-Matic record changers are designed to play in automatic sequence a stack of records and shut off both the changer and amplifier after playing the last record.The changer plays at four different turntable speeds; 16 2/3, 33 1/3, 45 or 78 r.p.m.

  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
