A466A Solid State Long Distance Radio Ch= 8AT16X

A466A Solid State Long Distance Radio Ch= 8AT16X; Zenith Radio Corp.; (ID = 1364408) Radio A466A Solid State Long Distance Radio Ch= 8AT16X; Zenith Radio Corp.; (ID = 1364409) Radio
A466A Solid State Long Distance Radio Ch= 8AT16X; Zenith Radio Corp.; (ID = 1364410) Radio
Use red slider bar for more.
A466A Solid State Long Distance Radio Ch= 8AT16X; Zenith Radio Corp.; (ID = 1364408) Radio
Zenith Radio Corp.;: A466A Solid State Long Distance Radio Ch= 8AT16X [Radio] ID = 1364408 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model A466A Solid State Long Distance Radio Ch= 8AT16X, Zenith Radio Corp.; Chicago, IL:
Copy from Ebay seller justdealz1.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1961 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out 7 W (max.)
from Radiomuseum.org Model: A466A Solid State Long Distance Radio Ch= 8AT16X - Zenith Radio Corp.; Chicago,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 302 x 169 x 117 mm / 11.9 x 6.7 x 4.6 inch
Notes Zenith Solid State Table Top AM-FM Clock Radio Model A-466-A.

Model page created by Franz Scharner. See "Data change" for further contributors.
