Trans-Oceanic (TransOceanic) A600 Ch= 6A41 brown leather

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374776) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374777) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374778) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374779) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374780) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374781) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374782) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374783) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374784) Radio

Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 374785) Radio
Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 215157) Radio Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 215158) Radio
Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 215159) Radio Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 939864) Radio
Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 939889) Radio Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 1045842) Radio
Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 1045843) Radio Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 1045845) Radio
Use red slider bar for more.
Trans-Oceanic A600 Ch= 6A41; Zenith Radio Corp.; (ID = 215157) Radio
Zenith Radio Corp.;: Trans-Oceanic A600 Ch= 6A41 [Radio] ID = 215157 450x436
Select picture or schematic to display from thumbnails on the right and click for download.
For model Trans-Oceanic (TransOceanic) A600 Ch= 6A41 brown leather, Zenith Radio Corp.; Chicago, IL

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 1U4 1L6 1U4 1U5 3V4 50A1
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Line / Batteries (any type) / 9 & 90; 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 10 W (unknown quality)
from Radiomuseum.org Model: Trans-Oceanic A600 Ch= 6A41 [brown leather] - Zenith Radio Corp.; Chicago,
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 17 x 11 x 8 inch / 432 x 279 x 203 mm
Notes Bryant/Cones; See also the article here.
Siehe auch den Artikel hier.
Si veda anche l'articolo in questa pagina.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Price in first year of sale 160.00 $

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
