X-1814R Ch= 16X20

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1955/1956

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
126650

- alternative name: Chicago Radio Lab

Schematics

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773562) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773563) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773564) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773565) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773566) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773567) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773568) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773569) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773570) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773571) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773572) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773573) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773574) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773575) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773576) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773577) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2773578) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133013) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133014) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133015) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133016) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133017) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133018) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133019) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133020) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133021) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133022) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133023) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133024) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 2133025) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (3)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 765055) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 736719) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 765056) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 765057) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 765058) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 765059) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)

X-1814R Ch= 16X20; Zenith Radio Corp.; (ID = 498707) Television — Zenith Radio Corp.; X-1814R Ch= 16X20 (2)
Sams photofact Set 310 Folder 14 3-1956.

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
16

Valves / Tubes
5BK7A 5U8 3CB6 3CB6 6AU8 6AU8 3BN6 5AQ5 3BY6 or 3CS6 12B4A 3AL5 6SN7GTB 12CU6 or 12BQ6GA or 12BQ6GTB 1B3GT 12AX4GTA 17AVP4

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

Power out
1.3 W (1.6 W max.)

from Radiomuseum.org
Model: X-1814R Ch= 16X20 - Zenith Radio Corp.; Chicago,

Shape
Tablemodel, with any shape - general.

Notes
The ZENITH model X1814R is a 17" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with VHF-tuner S-22452, chassis 16X20 and picture tube 17AVP4.

Literature/Schematics (1)
Photofact Folder, Howard W. SAMS (Set 310 Folder 14 3-1956)

Literature/Schematics (2)
Zenith Service Manual - 1956 Television Receivers TV-15
