Y1816RU Ch= 16Y20U

Zenith Radio Corp.; Chicago, IL

  • Year
  • 1955/1956
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 277116
    • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 17
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 110-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1.3 W (1.6 W max.)
  • from Radiomuseum.org
  • Model: Y1816RU Ch= 16Y20U - Zenith Radio Corp.; Chicago,
  • Notes
  • The Zenith Y1816RU is a 17" b/w TV with US standard VHF Tuner channels 2 thru 13, 14 thru 83 UHF. Equipped with chassis 16Y20U, VHF tuner S-24383, UHF tuner S-22530 and picture tube 17AVP4 or 17AVP4A.

  • Author
  • Model page created by John Kusching. See "Data change" for further contributors.
