• Year
  • 1956
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 278791
    • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 17
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Y2222E Ch= 17Y20 - Zenith Radio Corp.; Chicago,
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 22.75 x 18.5 x 20.5 inch / 578 x 470 x 521 mm
  • Notes
  • The ZENITH model Y2222E is a 21" b/w TV with US standard VHF Tuner channels 2 thru 12 equipped with VHF-tuner S-24392, chassis 17Y20 and picture tube 21ALP4A.

    Cabinet in two tone decorator color combinations
    Zenith  The Cloister Y2222E:
    in Ecru Beige top and Suede Brown Bottom colors - top is covered in genuine imported Irish Linen
    Zenith The Cloister Y2222Y - in solid Ebony color
    Zenith The Cloister Y2222R - in solid Maroon color
    Zenith The Cloister Y2222C - in Limestone White and Slate Gray colors

    Removable face plate glass, built-in carry handles

    Stand with caster at extra cost




  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
