Y2636R Ch= 17Y23

Zenith Radio Corp.; Chicago, IL

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Zenith Radio Corp.; Chicago, IL

Year
1955/1956

Category
Television Receiver (TV) or Monitor

Radiomuseum.org ID
282388

- alternative name: Chicago Radio Lab

Schematics

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117876) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117877) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117878) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117879) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117880) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117881) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117882) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117883) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117884) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117885) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117886) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117887) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117888) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117889) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117890) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117891) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117892) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117893) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117894) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117895) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117896) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117897) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117898) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117899) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117900) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117901) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117902) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117903) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117904) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2117905) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (3)

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2100636) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (2)
USA_Zenith_model Y2636 copy from folder.

Y2636R Ch= 17Y23; Zenith Radio Corp.; (ID = 2809557) Television — Zenith Radio Corp.; Y2636R Ch= 17Y23 (2)
Zenith Print Ad

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
17

Valves / Tubes
6BK7A 6U8 3CB6 3CB6 3CB6 6AU8 6BN6 6AQ5 6BU8 6CM7 6CN7 6CG7 6DQ6 1B3GT 6AU4 5U4GA 24DP4A

Main principle
Superhet with RF-stage

Wave bands
VHF incl. FM and/or UHF (see notes for details)

Power type and voltage
Alternating Current supply (AC) / 60 cycles, 110-120 Volt

Loudspeaker
2 Loudspeakers

Power out
1.3 W (1.6 W max.)

from Radiomuseum.org
Model: Y2636R Ch= 17Y23 - Zenith Radio Corp.; Chicago,

Shape
Tablemodel, with any shape - general.

Dimensions (WHD)
25.75 x 22 x 22.5 inch / 654 x 559 x 572 mm

Notes
The Zenith Y2636R is a 24" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis 17Y23, VHF tuner S-24392 and picture tube 24DP4A.

Zenith 24 Series Table Television Model THE LEXINGTON Y2636R
Cabinet in grained Mahogany color

Dual Speaker System
Easy out face plate glass

Matching swivel base at extra cost.

Zenith THE LEXINGTON Y2636E - Cabinet in grained Blond Oak color

Literature/Schematics (1)
Zenith Service Manual - 1956 Television Receivers TV-16

Author
Model page created by John Kusching. See "Data change" for further contributors.
