• Year
  • 1956/1957
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 257550
    • alternative name: Chicago Radio Lab

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 110-120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Power out
  • 1.3 W (1.6 W max.)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: Z1814R Ch= 16Z20 - Zenith Radio Corp.; Chicago,
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Notes
  • The Zenith Z1814R is a 17" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis 16Z20 and picture tube 17AVP4.

    The following models make up the Z1814 family of televisions:

    Model Channels Cabinet Color
    Z1814R VHF only Mahogany
    Z1814RU VHF and UHF Mahogany
    Z1814Y VHF only Ebony
    Z1814YU VHF and UHF Ebony



  • Literature/Schematics (2)
  • - - Manufacturers Literature (Zenith 1957 Television Receivers Service Manual TV-17 Dated 5-29-56)
