Z2637R Ch= 17Z23

• Country
• United States of America (USA)

• Manufacturer / Brand
• Zenith Radio Corp.; Chicago, IL

• Year
• 1956/1957

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 261625

• • alternative name: Chicago Radio Lab

• Picture
• Schematics

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• 6BN4 6CG8 3CB6 3CB6 3CB6 6AU8 3BN6 6AQ5 6BU8 6CM7 6CN7 6CG7 6DQ6 1B3GT 6AU4GT or 6AU4GTA 5U4GA or 5U4GB 24DP4A

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 60 cycles, 110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 1.3 W (1.6 W max.)

• from Radiomuseum.org
• Model: Z2637R Ch= 17Z23 - Zenith Radio Corp.; Chicago,

• Notes

• The Zenith Z2637R is a 24" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with chassis 17Z23 and picture tube 24DP4A.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 343, folder 18 dated 1-57)

• Literature/Schematics (2)
• - - Manufacturers Literature (Zenith 1957 Television Receivers Service Manual TV-17 Dated 5-29-56)

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
