Rundfunkwürfel FW3

Zerdik; Wien

  • Year
  • 1932
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 30009

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • TRF with regeneration; 2 AF stage(s)
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 150; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Rundfunkwürfel FW3 - Zerdik; Wien
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 279 x 230 x 190 mm / 11 x 9.1 x 7.5 inch
  • Notes
  • Wellenbereichsumschaltung : "2000m - 600m"

  • Price in first year of sale
  • 220.00 ATS
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
