Inconnu - Unknown 1

Zodiac-Radio; Paris

Data
Forum
Pictures
Collections

  • Year
  • 1937 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 237691

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF (Tuned-Radio-Frequency but use of regeneration unknown)
  • Tuned circuits
  • 2 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 cm = 4.7 inch
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Inconnu - Unknown 1 - Zodiac-Radio; Paris
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 140 x 150 x 140 mm / 5.5 x 5.9 x 5.5 inch
  • Notes

  • Montage à réaction. Fonctionne sur secteur alternatif 110 volt à l'aide d'une résistance (ou cordon chauffant).

    Mallette gainé simili-cuir, 2 couvercles.

  • Net weight (2.2 lb = 1 kg)
  • 2.3 kg / 5 lb 1.1 oz (5.066 lb)
  • Author
  • Model page created by Giovanni Signorelli. See "Data change" for further contributors.
