2SA562

Information - Help
ID = 38104

Country:
Japan
Brand: Toshiba Corporation; Tokyo
Tube type:  Transistor   Universal
Identical to 2SA562
Similar Tubes
Normally replaceable-slightly different:
  BC328

Base Wires
Filament Solid State
Description PNP silicon epitaxial transistor intended as AF low power amplifier / for universal purpose.

Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
6 x 6 x 5 mm / 0.24 x 0.24 x 0.20 inch
Weight 1 g / 0.04 oz
Information source
  2SA562: Funkschau 24/76
Egon Strampe

2SA562: Sammlung
Karlheinz Fischer


2SA562: TTT Steidle 1981
Günther Stabe


2SA562: Toshiba Semiconductor 1983
Thomas Günzel


Usage in Models 1= 1965?? ; 2= 1970?? ; 1= 1970 ; 1= 1971 ; 1= 1973 ; 1= 1974? ; 1= 1974 ; 3= 1975?? ; 1= 1975 ; 1= 1976?? ; 1= 1976? ; 1= 1976 ; 1= 1977 ; 1= 1978? ; 2= 1980?? ; 1= 1981? ; 1= 1986?? ; 1= 1990?? ; 1= 1991??

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):23
