Allegro 21W/UKW

Allegro 21W/UKW; REMA, Fabrik für (ID = 27865) Radio
Use red slider bar for more.
Allegro 21W/UKW; REMA, Fabrik für (ID = 27865) Radio
REMA, Fabrik für: Allegro 21W/UKW [Radio] ID = 27865 691x570
Select picture or schematic to display from thumbnails on the right and click for download.
For model Allegro 21W/UKW, REMA, Fabrik für Rundfunk, Elektrotechnik und Mechanik, Stollberg (Ostd.)

Country:  Germany
Manufacturer / Brand:  REMA, Fabrik für Rundfunk, Elektrotechnik und Mechanik, Stollberg (Ostd.)
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECH81 ECH81 EF80 EF80 EM11 EABC80 EL12 AZ12
schematic requested
Main principle Super-Heterodyne (Super in general); ZF/IF 468 kHz
Tuned circuits 10 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker 3 Loudspeakers / Ø 24.5 cm = 9.6 inch
Power out 8 W (unknown quality)
from Radiomuseum.org Model: Allegro 21W/UKW - REMA, Fabrik für Rundfunk,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 610 x 430 x 305 mm / 24 x 16.9 x 12 inch
Notes KW-Lupe; Höhen-und Tiefenreglung mit optischer Anzeige; regelbares 4-Kreis-ZF-Bandfilter.
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Price in first year of sale 626.00 DM
External source of data E. Erb 3-907007-36-0
Source of data Gebrauchswaren-Katalog 1954 / Radiokatalog Band 2, Ernst Erb
Mentioned in Deutsche Funk-Technik (Deutsche Funktechnik) [DDR] (Radio und Fernsehen 6/1956)
