• Country
• Germany

• Manufacturer / Brand
• Telefunken Deutschland (TFK), (Gesellschaft für drahtlose Telegraphie Telefunken mbH

• Year
• 1959/1960

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 22348

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• ECC85 ECH81 EF89 EF89 EM84 EABC80 ECC83 ECC83 EL84 EL84

• Main principle
• Superheterodyne (common)

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Hymnus Hi-Fi Stereo 2004 - Telefunken Deutschland TFK,

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 1270 x 870 x 440 mm / 50 x 34.3 x 17.3 inch

• Net weight (2.2 lb = 1 kg)
• 68 kg / 149 lb 12.5 oz (149.78 lb)

• Price in first year of sale
• 1,198.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1959/60
