00A

Information - Help
ID = 4070

Country:
United States of America (USA)
Brand:
Developer: General Electric Co. (GE); Bridgeport CT, Syracuse NY
Tube type:  Gas Triode   Detector
Identical to 00A = UX200A = D400A = 200A = 5VD_vanHorne = PA200A = 200X00-A = TC200A = SX200A
Similar Tubes
Normally replaceable-slightly different:
  PR-1-A
First Source (s)
1926 : -- Collector info (Sammler)

Base UX-Base (4 Pins (2 thick, USA 1924, UX) (Codex=Bo)
Was used by Radio/TV-reception etc.
Filament Vf 5 Volts / If 0.25 Ampere / Direct
Description

For use as a supersensitive detector in amateur receiving sets.


Dimensions (WHD)
incl. pins / tip
x 108 x 45 mm / x 4.25 x 1.77 inch
Weight 47 g / 1.66 oz
Information source Essential Characteristics, GE 1973
Taschenbuch zum Röhren-Codex 1948/49

00A: MK-Röhrentabelle
Daniel Consales

171_1.png 00A: Telefunken Werkstattbuch
Wolfgang Bauer


Just Qvigstad
00A: Grundig Rö-Tabu, zum M1, Band 3, 1948
Anonymous 15 Collector

More ...
Usage in Models 7= 1927?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):7
