LM2576
|
Country:
United States of America (USA)
|
|
| Identical to |
LM2576
|
| Base |
Wires
|
| Description |
Aufbau/internal: IC (__ Trans., __ Widerst., __ Dioden, __ Kond.);
Form/Case/Outline: TO-220-5 [Pentawatt] (LM2576T-5.0 / LM2576T-12.0 / LM2576T-ADJ*) | TO-263-5 (LM2576S-xx) | LPDD (LM2576J-xx)
Type/Application: Power Converter, Step Down, 3 A;
Daten/electr.data: Uin: 4...40 V; Uout: 3.3 V / 5 V / 12 V / 15 V or 1.23...37 V adjustable*; f switch: 52 kHz; Pd: __ W; t max j: +125 °C;
Manufactured by NSC - National Semiconductor Corp., USA
3.3V / 15 V von Bay Linear, CA (USA)
Ähnlich/similar: N2576S[G]-x (NIKOS),...
-
|
Dimensions (WHD)
incl. pins / tip |
10 x 16 x 4 mm / 0.39 x 0.63 x 0.16 inch |
| Weight |
2 g / 0.07 oz |
| Information source |
- - Manufacturers Literature NSC, Linear Bay
|
LM2576: Bay Linear
Günther Stabe † 19.8.20
More ...
|
LM2576: Bay LInear
Günther Stabe † 19.8.20
More ...
|
|
LM2576: Bay Linear
Günther Stabe † 19.8.20
|
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):1
