For model Integrated Stereo Amplifier E-305, Accuphase Laboratory; Yokohama:
Accuphase Prospekt

Country:  Japan
Manufacturer / Brand:  Accuphase Laboratory; Yokohama
Year: 1987 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 77:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 100; 117; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 360 W (undistorted)
from Radiomuseum.org Model: Integrated Stereo Amplifier E-305 - Accuphase Laboratory; Yokohama
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 475 x 170 x 375 mm / 18.7 x 6.7 x 14.8 inch
Notes

Accuphase Integrated Stereo Amplifier Model E-305
Power output:
130 watts per channel into 8Ω (stereo)
180 watts per channel into 4Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.02%
Damping factor: 100
Input sensitivity: 0.08mV (MC), 2.5mV (MM), 120mV (line)
Signal to noise ratio: 66dB (MC), 86dB (MM), 106dB (line)
Tone Controls:
Bass 300Hz +/-10dB (50Hz)
Treble 3000Hz +/-10dB (20000Hz)
Loudness
Subsonic Filter 17Hz, -12dB
Speaker load impedance: 4Ω to 16Ω

Semiconductors:
77x transistors, 34x FET's, 20x IC's, 78x diodes

Net weight (2.2 lb = 1 kg) 20.5 kg / 45 lb 2.5 oz (45.154 lb)
Mentioned in -- Original prospect or advert (Accuphase Sales Brochure)
Literature/Schematics (1) - - Manufacturers Literature (Service Manual)

Model page created by Franz Scharner. See "Data change" for further contributors.
