Sonofil 104

Sonofil 104; ACEC, Ateliers de (ID = 947412) R-Player Sonofil 104; ACEC, Ateliers de (ID = 947403) R-Player
Sonofil 104; ACEC, Ateliers de (ID = 947404) R-Player Sonofil 104; ACEC, Ateliers de (ID = 947406) R-Player
Sonofil 104; ACEC, Ateliers de (ID = 947407) R-Player Sonofil 104; ACEC, Ateliers de (ID = 947408) R-Player
Sonofil 104; ACEC, Ateliers de (ID = 947409) R-Player Sonofil 104; ACEC, Ateliers de (ID = 947410) R-Player
Sonofil 104; ACEC, Ateliers de (ID = 1126770) R-Player Sonofil 104; ACEC, Ateliers de (ID = 1284655) R-Player
Use red slider bar for more.
Sonofil 104; ACEC, Ateliers de (ID = 947412) R-Player
ACEC, Ateliers de: Sonofil 104 [R-Player] ID = 947412 800x450
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sonofil 104, ACEC, Ateliers de Constructions Électriques de Charleroi; Charleroi

Country:  Belgium
Manufacturer / Brand:  ACEC, Ateliers de Constructions Électriques de Charleroi; Charleroi
Year: 1950 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 7: 6SJ7 6J7 6V6GT 6V6GT 6E5 6V6GT 5Z4
Main principle Audio-Amplification
Wave bands - without
Details Other Combination - see Notes
Power type and voltage Alternating Current supply (AC) / 110; 130; 145; 190; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: Sonofil 104 - ACEC, Ateliers de
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 497 x 310 x 350 mm / 19.6 x 12.2 x 13.8 inch
Notes Wire and record player.

Riproduttore a filo d'acciaio magnetico e giradischi
Net weight (2.2 lb = 1 kg) 23.9 kg / 52 lb 10.3 oz (52.643 lb)

Model page created by Giovanni Scalavino. See "Data change" for further contributors.



All listed radios etc. from ACEC, Ateliers de Constructions Électriques de Charleroi; Charleroi
Here you find 233 models, 225 with images and 38 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
