ACEC, Ateliers de: 5155 [Radio] ID = 2396904 1400x881
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1958 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | 7: OC44 OC45 OC45 OC71 OC71 OC72 OC72 OA79 |
|---|
| Main principle | Superheterodyne (common) |
|---|---|
| Wave bands | Broadcast (MW) and Long Wave. |
| Details | |
| Power type and voltage | Dry Batteries / 6 × 1,5 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | |
| from Radiomuseum.org | Model: 5155 - ACEC, Ateliers de |
| Material | Leather / canvas / plastic - over other material |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 310 x 200 x 110 mm / 12.2 x 7.9 x 4.3 inch |
| Notes | . |
| Net weight (2.2 lb = 1 kg) | 2.5 kg / 5 lb 8.1 oz (5.507 lb) |
| Source of data | - - Data from my own collection |
Model page created by Jean-Paul Moriamé. See "Data change" for further contributors.
