52-G280 GR280

52-G280; ACER A.C.E.R. / (ID = 253354) Kit

52-G280; ACER A.C.E.R. / (ID = 253355) Kit
52-G280; ACER A.C.E.R. / (ID = 252884) Kit
Use red slider bar for more.
52-G280; ACER A.C.E.R. / (ID = 252884) Kit
ACER A.C.E.R. /: 52-G280 [Kit] ID = 252884 678x495
Select picture or schematic to display from thumbnails on the right and click for download.
For model 52-G280 GR280, ACER (A.C.E.R.) / Omnium Commercial d'Électricité et de Radio; Rueil, Paris

Country:  France
Manufacturer / Brand:  ACER (A.C.E.R.) / Omnium Commercial d'Électricité et de Radio; Rueil, Paris
Year: 1952 Category: Kit (Parts plus instruction) or building instructions only
Valves / Tubes 6: ECH42 EF41 EBC41 EL41 EM34 GZ41
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: 52-G280 [GR280] - ACER A.C.E.R. / Omnium
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 520 x 320 x 250 mm / 20.5 x 12.6 x 9.8 inch
Notes 2 modèles d'ébénisteries (GR280 et C280), 2 OC dont une bande étalée.
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Radio Constructeur et Dépanneur 1952

Model page created by Peter Hoddow. See "Data change" for further contributors.
