Aciko ACR270

Aciko ACR270; Aciko brand (ID = 373828) Radio

Aciko ACR270; Aciko brand (ID = 373830) Radio

Aciko ACR270; Aciko brand (ID = 373833) Radio
Aciko ACR270; Aciko brand (ID = 802472) Radio Aciko ACR270; Aciko brand (ID = 373873) Radio
Aciko ACR270; Aciko brand (ID = 802474) Radio
Use red slider bar for more.
Aciko ACR270; Aciko brand (ID = 802472) Radio
Aciko brand: Aciko ACR270 [Radio] ID = 802472 900x740
Select picture or schematic to display from thumbnails on the right and click for download.
For model Aciko ACR270, Aciko (brand)

Country:  Japan
Manufacturer / Brand:  Aciko (brand)
Year: 1975–1980 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 21:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 117; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Aciko ACR270 - Aciko brand
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Notes Cassette recorder. 21 Transistors: 7x 2SC372, 2SC373, 2SC374, 2SC378, 4x 2SC380, 2x 2SC394, 2x 2SC732, 2SC735, 2x 2SD439.
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
