17DX11 Ch= 19B1
Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Country
- United States of America (USA)
- Manufacturer / Brand
- Admiral (brand) Continental Radio & Television Co.; Chicago, IL
- Year
- 1953 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 113558
-
- alternative name: Continental Radio & TV
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- 6BC5 6J6 6CB6 6CB6 6U8 6AL5 6CB6 6AU6 6AL5 6AV6 6AS5 12AU7 6S4 6SN7GT 6BQ6GT 6AX4GT 1B3GT 5U4G 17BP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: 17DX11 Ch= 19B1 - Admiral brand Continental
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Admiral model 17DX11 is a 17” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 19B1, VHF tuner 94D46-2 and picture tube 17BP4A.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 210, folder 2, dated 7-53)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
