• Year
  • 1959 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 143110
    • alternative name: Continental Radio & TV

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 16
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • from Radiomuseum.org
  • Model: C22UM24 Ch= 20US6 - Admiral brand Continental
  • Notes
  • Sams photofact set 480 folder 1 date 4-60 features the Admiral models C22M11, C22M12, C22M13, C22M22, C22M23, C22M24, L22M22, L22M23, L22M24, T22M10, T22M11, T22M12, T22M13, all with chassis 20S6 and the models C22UM11, C22UM12, C22UM13,C22UM22, C22UM23, C22UM24, L22UM22, L22UM23, L22UM24, T22UM10, T22UM11, T22UM12, T22UM13 with chassis 20US6 as the same schematic.
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
