RF Signal Generator E2

RF Signal Generator E2; Advance Instruments; (ID = 283189) Equipment

RF Signal Generator E2; Advance Instruments; (ID = 283190) Equipment
RF Signal Generator E2; Advance Instruments; (ID = 425374) Equipment RF Signal Generator E2; Advance Instruments; (ID = 426306) Equipment
RF Signal Generator E2; Advance Instruments; (ID = 426308) Equipment RF Signal Generator E2; Advance Instruments; (ID = 1727971) Equipment
Use red slider bar for more.
RF Signal Generator E2; Advance Instruments; (ID = 425374) Equipment
Advance Instruments;: RF Signal Generator E2 [Equipment] ID = 425374 900x640
Select picture or schematic to display from thumbnails on the right and click for download.
For model RF Signal Generator E2, Advance Instruments; Hainault Essex:
My early 1950s Advance Type E model 2 signal generator.

Country:  Great Britain (UK)
Manufacturer / Brand:  Advance Instruments; Hainault Essex
alternative name

Advance Components Ltd.
Year: 1951 Category: Service- or Lab Equipment
Valves / Tubes 3: ECC91 6SN7GT 6X5GT
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 105-125;210-250 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: RF Signal Generator E2 - Advance Instruments; Hainault
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 13 x 10.5 x 7.75 inch / 330 x 267 x 197 mm
Notes RF signal generator covers 100 kHz to 100 MHz in six ranges, internal or external AF modulation.
Net weight (2.2 lb = 1 kg) 6.8 kg / 14 lb 15.6 oz (14.978 lb)
Collectors' prices
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Advance Instruments; Hainault Essex
Here you find 37 models, 31 with images and 13 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
