• Year
  • 1960 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 192063

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 2
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 105 - 250 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Signal Generator P1 - Advance Electronics /
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 307 x 233 x 126 mm / 12.1 x 9.2 x 5 inch
  • Notes
  • RF signal generator with internal or external modulation (AM)
    Wave bands:
    A: 30 MHz - 100 MHz
    B: 10 MHz - 30 MHz
    C: 3 MHz - 10 MHz
    D: 1 MHz - 3 MHz
    E: 300 kHz - 1000 KHz
    F: 100 kHz - 300 kHz
  • Net weight (2.2 lb = 1 kg)
  • 5.4 kg / 11 lb 14.3 oz (11.894 lb)
