Bajazzo Sport 3591K

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531359) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531361) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531362) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531363) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531364) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531365) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531366) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531367) Radio

Bajazzo Sport 3591K; AEG Radios Allg. (ID = 531369) Radio
Bajazzo Sport 3591K; AEG Radios Allg. (ID = 326859) Radio Bajazzo Sport 3591K; AEG Radios Allg. (ID = 2021623) Radio
Bajazzo Sport 3591K; AEG Radios Allg. (ID = 2357721) Radio Bajazzo Sport 3591K; AEG Radios Allg. (ID = 2357722) Radio
Bajazzo Sport 3591K; AEG Radios Allg. (ID = 2357723) Radio
Use red slider bar for more.
Bajazzo Sport 3591K; AEG Radios Allg. (ID = 326859) Radio
AEG Radios Allg.: Bajazzo Sport 3591K [Radio] ID = 326859 462x402
Select picture or schematic to display from thumbnails on the right and click for download.
For model Bajazzo Sport 3591K, AEG (Radios) Allg.Elektricitäts-Ges.

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF106 AF135 AF136 AF138 AF137 AC122 AC116 AC117 AC117
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.8 W (unknown quality)
from Radiomuseum.org Model: Bajazzo Sport 3591K - AEG Radios Allg.Elektricitäts-
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 175 x 85 mm / 11 x 6.9 x 3.3 inch
Notes Betrieb im Auto über Autohalterung (54,- DM) aus 6-V- oder 12-V-Autobatterie, dann Ausgangsleistung 2,3 W.
Baugleich mit Telefunken Bajazzo Sport 3591K.
Net weight (2.2 lb = 1 kg) 2.8 kg / 6 lb 2.7 oz (6.167 lb)
Price in first year of sale 399.00 DM
Collectors' prices
Source of data Handbuch VDRG 1964/1965

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
