FM/AM/LW Radio TR 4131

FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2310894) Radio FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2310892) Radio
FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2310891) Radio FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2310890) Radio
FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2310893) Radio FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2379677) Radio
FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2379678) Radio FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2379679) Radio
FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2379680) Radio FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2379681) Radio
Use red slider bar for more.
FM/AM/LW Radio TR 4131; AEG Radios Allg. (ID = 2310894) Radio
AEG Radios Allg.: FM/AM/LW Radio TR 4131 [Radio] ID = 2310894 1351x1684
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM/AM/LW Radio TR 4131, AEG (Radios) Allg.Elektricitäts-Ges.

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 2011 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) CD2003GP TDA2822
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 50Hz, 230 / C: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: FM/AM/LW Radio TR 4131 - AEG Radios Allg.Elektricitäts-
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 215 x 162 x 80 mm / 8.5 x 6.4 x 3.1 inch
Net weight (2.2 lb = 1 kg) 0.630 kg / 1 lb 6.2 oz (1.388 lb)

Model page created by Ottmar Lauth. See "Data change" for further contributors.
