Geadola

Geadola ; AEG Radios Allg. (ID = 2145030) Speaker-P Geadola ; AEG Radios Allg. (ID = 2145031) Speaker-P
Geadola ; AEG Radios Allg. (ID = 2145032) Speaker-P Geadola ; AEG Radios Allg. (ID = 2145033) Speaker-P
Geadola ; AEG Radios Allg. (ID = 2145034) Speaker-P Geadola ; AEG Radios Allg. (ID = 2145035) Speaker-P
Geadola ; AEG Radios Allg. (ID = 2145037) Speaker-P Geadola ; AEG Radios Allg. (ID = 27) Speaker-P
Geadola ; AEG Radios Allg. (ID = 395969) Speaker-P Geadola ; AEG Radios Allg. (ID = 1273822) Speaker-P
Use red slider bar for more.
Geadola ; AEG Radios Allg. (ID = 2145030) Speaker-P
AEG Radios Allg.: Geadola [Speaker-P] ID = 2145030 1400x1046
Select picture or schematic to display from thumbnails on the right and click for download.
For model Geadola, AEG (Radios) Allg.Elektricitäts-Ges.

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1931/1932 Category: Loudspeaker, headphone or earphone
Valves / Tubes 1: RGN1054
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Geadola - AEG Radios Allg.Elektricitäts-
Material Wooden case
Notes Elektrodyn LS, 2 Var. GL und Wechselstrom
Umschaltbar für einfache, Schirmgitter- und Kraft-Endröhren.
Price in first year of sale 125.00 RM
Source of data AEG Hilfsbuch für den Funkhändler / Radiokatalog Band 1, Ernst Erb
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from AEG (Radios) Allg.Elektricitäts-Ges.
Here you find 805 models, 692 with images and 412 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
