Portable CD Stereo Radio System SR4339

ID = 325431

{gbW: "1400", gbH: "1546", mW: "339.0", mH: "375", kb: "190 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "1612", mW: "325.0", mH: "375", kb: "265 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "1282", mW: "409.0", mH: "375", kb: "152 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.:[br]Batteriefach geoeffnet.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "645", mW: "500", mH: "230.0", kb: "88 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "1151", mW: "456.0", mH: "375", kb: "119 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.:[br]CD-Fach geoeffnet.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "1023", mW: "500", mH: "365.0", kb: "109 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "979", mW: "500", mH: "349.0", kb: "90 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"} {gbW: "1400", gbH: "1050", mW: "500", mH: "375", kb: "162 KB", notes: "For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.", title: "AEG Radios Allg. Portable CD Stereo Radio System SR4339 from Michael Mischke (1)", ite: "1"}

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592004) Radio

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592010) Radio

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592009) Radio

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592005) Radio

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592006) Radio

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592007) Radio

Portable CD Stereo Radio System SR4339; AEG Radios Allg. (ID = 2592011) Radio

Use red slider bar for more.

AEG Radios Allg.: Portable CD Stereo Radio System SR4339 [Radio] ID = 2592004 1400x1546

Select picture or schematic to display from thumbnails on the right and click for download.

For model Portable CD Stereo Radio System SR4339, AEG (Radios) Allg.Elektricitäts-Ges.

Country:

Germany

Manufacturer / Brand:

AEG (Radios) Allg.Elektricitäts-Ges.

Year: 2012 ??

Category: Broadcast Receiver - or past WW2 Tuner

Semiconductors (the count is only for transistors)

Semiconductors present. TA2111 unknown_IC M5673 EN25F10 D9258 TA8227 µA78M05

Main principle	Superheterodyne (common)
Wave bands	Broadcast (BC) and FM or UHF.
Details	Other Combination - see Notes
Power type and voltage	Line / Batteries (any type) / 220-240 / R14: 6 × 1,5 Volt
Loudspeaker	2 Loudspeakers / Ø 6.5 cm = 2.6 inch
Power out
from Radiomuseum.org	Model: Portable CD Stereo Radio System SR4339 - AEG Radios Allg.Elektricitäts-
Material	Plastics (no bakelite or catalin)
Shape	Portable set > 8 inch (also usable without mains)
Dimensions (WHD)	240 x 130 x 233 mm / 9.4 x 5.1 x 9.2 inch
Notes	Kombination aus CD-Player, USB-MP3-Player und AM/FM-Radio. FM-Empfang (Stereo) über 40 cm Teleskopantenne, AM-Empfang über eingebaute Ferritantenne. Leistungsaufnahme: 12 Watt Halbleiterliste nicht vollständig.
Net weight (2.2 lb = 1 kg)	1.311 kg / 2 lb 14.2 oz (2.888 lb)

Model page created by Michael Mischke. See "Data change" for further contributors.

All listed radios etc. from AEG (Radios) Allg.Elektricitäts-Ges.
Here you find 810 models, 693 with images and 410 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Michael Mischke (D)
