Vielfach-Ladegerät GBWV III (GBWV 3)

AEG (Radios) Allg.Elektricitäts-Ges.

  • Year
  • 1934 ??
  • Category
  • Power supply/conditioner or battery or charger
  • Radiomuseum.org ID
  • 181949

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Vielfach-Ladegerät GBWV III - AEG Radios Allg.Elektricitäts-
  • Shape
  • Console with any shape - in general
  • Notes
  • Vielfach-Ladergerät mit zweianodiger Glühkathodenröhre. Verwendung zur gewerblichen Ladung von Heizakkus in zwei Ladekreisen zu je 1 bis 40 Zellen, Ausgangsstrom umschaltbar 6 und 10A, bzw. 3A je Ladekreis bei Vollast. Regelung der Gleichspannung bzw. des Ladestroms durch zwei zehnstufige Schalter an der Sekundärwicklung und an der separaten Ladetafel.
  • Author
  • Model page created by Georg Richter. See "Data change" for further contributors.
