L2RK
Use red slider bar for more.
AG für: L2RK [Radio] ID = 1612765 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1923/1924 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 2: |
|---|
| Main principle | TRF without regeneration |
|---|---|
| Tuned circuits | 2 AM circuit(s) |
| Wave bands | Broadcast only (MW). |
| Details | |
| Power type and voltage | Storage and/or dry batteries |
| Loudspeaker | - For headphones or amp. |
| Power out | |
| from Radiomuseum.org | Model: L2RK - AG für Radiotelephonie Radioma |
| Material | Wooden case |
| Shape | Tablemodel, Box - most often with Lid (NOT slant panel). |
| Notes | Dieser Zweiröhren-Empfänger L2RK bildete zusammen mit dem Zweiröhren-Verstärker L2ZN den Apparat L4. Siehe auch Radiofix III RK.
|
| External source of data | E. Erb 3-907007-36-0 |
| Source of data | Radiokatalog Band 2, Ernst Erb |
| Circuit diagram reference | Info Dr. H. Börner without schematic |
