4 Band Stereo Radio Cassette Recorder AJ-457FS

4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1552182) Radio
4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551411) Radio 4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551413) Radio
4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551415) Radio 4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551419) Radio
4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551420) Radio 4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551421) Radio
4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551422) Radio 4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551423) Radio
4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551426) Radio 4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551430) Radio
Use red slider bar for more.
4 Band Stereo Radio Cassette Recorder AJ-457FS; Akai Electric Co., (ID = 1551411) Radio
Akai Electric Co.,: 4 Band Stereo Radio Cassette Recorder AJ-457FS [Radio] ID = 1551411 933x808
Select picture or schematic to display from thumbnails on the right and click for download.
For model 4 Band Stereo Radio Cassette Recorder AJ-457FS, Akai Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1981 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 4: 2SC2458 2SC2458 2SC2458 2SC1959 TA7358 TA7757 TA7343 TA7668 TA7233
Main principle Superheterodyne (common)
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 110-127 / 220-240/ 6 x 1,5 Volt
Loudspeaker 2 Loudspeakers / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: 4 Band Stereo Radio Cassette Recorder AJ-457FS - Akai Electric Co., Ltd.; Tokyo
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 395 x 230 x 110 mm / 15.6 x 9.1 x 4.3 inch

Model page created by Daniel Rosha. See "Data change" for further contributors.



All listed radios etc. from Akai Electric Co., Ltd.; Tokyo
Here you find 568 models, 519 with images and 168 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
