• Country
• Japan

• Manufacturer / Brand
• Akai Electric Co., Ltd.; Tokyo

• Year
• 1978

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 144911

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 19

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Power out
• 38 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Receiver AA-1010L - Akai Electric Co., Ltd.; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 440 x 125 x 265 mm / 17.3 x 4.9 x 10.4 inch

• Notes
• 3-Band-HiFi-Stereo-Receiver mit 5 UKW-Stationstasten. Ratio-Mittenanzeige, Bass- und Höhenregelung, Loudness.
  Eingänge Phono, Tape, Aux, DIN. Ausgänge Tape, DIN, Kopfhörer (8 Ohm), Lautsprecher A,B,A+B.
  19 Transistoren, 5 Dioden, 4 IC's und 1 FET.

• Net weight (2.2 lb = 1 kg)
• 6.4 kg / 14 lb 1.6 oz (14.097 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
