For model AA-1115, Akai Electric Co., Ltd.; Tokyo:
Original prospekt in 1979.

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1979 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 26:
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 48 W (unknown quality)
from Radiomuseum.org Model: AA-1115 - Akai Electric Co., Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 480 x 123 x 268 mm / 18.9 x 4.8 x 10.6 inch
Notes ICs: 4
AM/FM-Stereo-Receiver mit 2× 24 Watt (Sinus) an 4 Ω.
Net weight (2.2 lb = 1 kg) 5.8 kg / 12 lb 12.4 oz (12.775 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
