Stereo Receiver AA-920

Stereo Receiver AA-920; Akai Electric Co., (ID = 2293235) Radio Stereo Receiver AA-920; Akai Electric Co., (ID = 2293234) Radio
Stereo Receiver AA-920; Akai Electric Co., (ID = 2293233) Radio Stereo Receiver AA-920; Akai Electric Co., (ID = 2293232) Radio
Stereo Receiver AA-920; Akai Electric Co., (ID = 2293237) Radio Stereo Receiver AA-920; Akai Electric Co., (ID = 2408084) Radio
Stereo Receiver AA-920; Akai Electric Co., (ID = 643200) Radio Stereo Receiver AA-920; Akai Electric Co., (ID = 556726) Radio
Stereo Receiver AA-920; Akai Electric Co., (ID = 2473096) Radio Stereo Receiver AA-920; Akai Electric Co., (ID = 2473097) Radio
Use red slider bar for more.
Stereo Receiver AA-920; Akai Electric Co., (ID = 2293235) Radio
Akai Electric Co.,: Stereo Receiver AA-920 [Radio] ID = 2293235 1400x807
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Receiver AA-920, Akai Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 44:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 80 W (unknown quality)
from Radiomuseum.org Model: Stereo Receiver AA-920 - Akai Electric Co., Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 454 x 155 x 330 mm / 17.9 x 6.1 x 13 inch
Notes ICs: 5
AM/FM-Stereo-Receiver mit 2× 40 Watt Sinus an 4 Ω.
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
