For model AM-U04, Akai Electric Co., Ltd.; Tokyo:
Original prospekt in 1980.

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1980 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 164 W (unknown quality)
from Radiomuseum.org Model: AM-U04 - Akai Electric Co., Ltd.; Tokyo
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 440 x 105 x 308 mm / 17.3 x 4.1 x 12.1 inch
Notes Stereo Vollverstärker mit 2 x 82 Watt Sinus an 4 Ohm.
Net weight (2.2 lb = 1 kg) 10.1 kg / 22 lb 3.9 oz (22.247 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
