AM-U61

AM-U61; Akai Electric Co., (ID = 1652455) Ampl/Mixer AM-U61; Akai Electric Co., (ID = 1652456) Ampl/Mixer
AM-U61; Akai Electric Co., (ID = 1652457) Ampl/Mixer AM-U61; Akai Electric Co., (ID = 1652458) Ampl/Mixer
Use red slider bar for more.
AM-U61; Akai Electric Co., (ID = 1652455) Ampl/Mixer
Akai Electric Co.,: AM-U61 [Ampl/Mixer] ID = 1652455 933x501
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM-U61, Akai Electric Co., Ltd.; Tokyo:
Thanks for Mr.Csengeri László, Pécs, Hungary and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1982 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 220 W (unknown quality)
from Radiomuseum.org Model: AM-U61 - Akai Electric Co., Ltd.; Tokyo
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 440 x 125 x 397 mm / 17.3 x 4.9 x 15.6 inch
Notes Stereo-Vollverstärker mit 2 x 110 Watt Sinus an 4 Ohm.
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.
