AP-100C

AP-100C; Akai Electric Co., (ID = 2272951) R-Player AP-100C; Akai Electric Co., (ID = 2272950) R-Player
AP-100C; Akai Electric Co., (ID = 2272952) R-Player AP-100C; Akai Electric Co., (ID = 2272953) R-Player
AP-100C; Akai Electric Co., (ID = 2272954) R-Player AP-100C; Akai Electric Co., (ID = 2272955) R-Player
AP-100C; Akai Electric Co., (ID = 556740) R-Player AP-100C; Akai Electric Co., (ID = 1176563) R-Player
AP-100C; Akai Electric Co., (ID = 1730510) R-Player AP-100C; Akai Electric Co., (ID = 1730511) R-Player
Use red slider bar for more.
AP-100C; Akai Electric Co., (ID = 2272951) R-Player
Akai Electric Co.,: AP-100C [R-Player] ID = 2272951 1024x576
Select picture or schematic to display from thumbnails on the right and click for download.
For model AP-100C, Akai Electric Co., Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Akai Electric Co., Ltd.; Tokyo
Year: 1979 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AP-100C - Akai Electric Co., Ltd.; Tokyo
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 440 x 140 x 350 mm / 17.3 x 5.5 x 13.8 inch
Notes Halbautomatischer Plattenspieler mit Riemenantrieb und 2 Geschwindigkeiten (33 und 45 Upm). Synchron-Motor, spitzengelagerter 300mm Plattenteller aus Al-Legierung..
Gehäuseausführung: Schwarz oder Mattsilber.
Net weight (2.2 lb = 1 kg) 6.1 kg / 13 lb 7 oz (13.436 lb)
Source of data -- Original prospect or advert

Model page created by Franz Scharner. See "Data change" for further contributors.



All listed radios etc. from Akai Electric Co., Ltd.; Tokyo
Here you find 550 models, 488 with images and 111 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
